Component Counters
  County EVO & County-S EVO Specs PDF

County EVO  |  Axial & Radial  |  SMD Components  |  Bar Code Reader & Printer  |  County-S EVO


AXIAL & RADIAL COMPONENTS

COUNTY EVO

The COUNTY EVO Component Counter is a microcomputer based instrument which counts axial and radial components on tape.
With the
SMD adaptor (8301.018) it can also count SMD components.
It counts in both directions.  It is equipped with a divider from 0.5 to 19 and a totalizer mode counting or Preset mode with an alarm that starts when the desired component number has been reached.

The county is available in two versions, one with a rechargeable battery, with barcode reader input, output for Printer & PC; Clock, and memory for 500 counting records (model 8301.088  110/220V) and the other one without battery (model 8301.087 110V/220V).

   County Specs PDF


      Maximum counting value: 999999 counts
     Minimum lead diameter: 0.4mm
     Axial component bandolier width: 55 - 110mm
     Radial component bandolier width: max 18mm
     Maximum component diameter : 14mm
     Display: 4 digits 13mm height
     Dimensions: 240x130x110mm
     Weight: 1.8Kg   (4 lbs.)

                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                   top

8301.087: County EVO 110/220V, 50-60Hz
8301.088: County EVO 110/220V, 50-60Hz with rechargeable battery, printer/pc output, barcode input, clock

Accessories for counting Axial & Radial Components:
8301.023
: Complete support for reel of axial and radial components (1 piece)
8301.025: Support handle (for 8301.023)

Accessories for counting SMD Components:
8301.018
: SMD County adaptor
8301.028: SMD support (1 piece)
8301.027: Worktop with 2 holding pins (no handle)
8301.030: SMD support handle (for 8301.028 and 8301.027)

8301.155: Barcode with coiled cord
8301.095: Direct thermal label printer
8301.096: 57x51mm, 1360 labels/roll

                                                                                                                                                                                                                                                                                                                                                                     top



AXIAL & RADIAL COMPONENTS

AXIAL & RADIAL COMPONENTS

The COUNTY Component Counter comes ready to count axial & radial components.  To count radial components, just remove the adjustable guide and turn it so the flat side will be in front of the optical head.  This flat side will guide the body of the radial components.
Before counting, it is necessary to select the number of leads per component by setting the divider with the up and down arrows.  Can enter up to 10 leads for component.





                                                                     top




AXIAL & RADIAL SUPPORT & HANDLE

The support for axial and radial components (8301.023) is a very useful accessory when the components come in a reel.
It is sold individually and a handle for it is available (8301.025)
















County with SMD adaptors, supports and label printer
BAR CODE READER & PRINTER FOR COUNTY EVO & COUNTY-S EVO

The Barcode Reader is small, light weight and ergonomically designed.  It includes a coiled cable.

A wider than usual scan angle provides the ability to read a longer bar code from a shorter distance, IP42 protection.
The barcode reader is connected and powered via a single cable without the hassle of two separate cables.


County shown with SMD Adaptor (8301.018) and SMD Supports (8301.028) and handle (8301.030)


The Thermal printer is a Direct thermal label printer built for ease-of-use and durability.  An AC adaptor 110-230Vac and data cable included. Maximum print width is 104mm, however the print is optimized for 57x51mm labels.




8301.155: Barcode with coiled cord 8301.095: Direct thermal label printer
8301.096: 57x51mm, 1360 labels/roll









SMD COMPONENTS

SMD ADAPTOR, SUPPORTS & HANDLE
8301.018, 8301.028, 8301.030

The SMD adaptor (8301.018) is a County component counter optional accessory to count SMD parts.
The maximum tape height is 56mm and the number of holes for component is min. 0.5 - max. 19.
Mounting the adaptor does not require any tools and it is locked in place by snap action
to the same shafts that hold the axial & radial guide. Component counting is achieved by counting the punched holes on the SMD tapes.
The SMD supports (8301.028) are sold individually and a handle is available (8301.030)
The worktop 8301.027 includes 2 holding pins.  At least one handle (8301.030) is recommended to rewind the reels.
The aluminum empty reel 8301.021 (360mm diameter) is an option available to speed the counting and rewinding process.
top

Worktop 8301.027                     County with worktop with handle and empty reel 8301.021





COUNTY-S EVO

The new COUNTY-S EVO replaces the old County-S SMD Component Counter.
The County-S EVO works by counting the holes on the tape.
It can operate in two different ways:
Totalizer: components are counted from a zero reference, tape feed is motorized and the counter automatically stops at the tape end, to prevent
loss of the total.
Preset mode: the desired component number is entered on the keyboard and the counter automatically stops when it reaches the corresponding component.

All functions are easy to operate with the help of interactive messages on the display.

County S Specs PDF


  On the screen are always visible:

  - Counting direction
  - Pitch number (holes per component)
  - Working mode (Totalizer, Preset or Rewind)
  - Name of the operator
  - Components counted
  - Date & Time or the last barcode reading.
top


Technical features
Display: 6 digits high efficiency LEDs
Maximum counting speed: 220 pc/sec (1 piece per hole)
Accuracy: ±1 piece
Holes per component: divider from 1 to 99 (and multiplier 2, 3, 4 for 0402, 0201 and 01005 components)
Maximum tape height: 56mm
Maximum reel diameter: 400mm (standard configuration), 650mm (with 8301.150 support)
Display: blue LCD with led backlight 160x104 pixel, visible area 74x46mm
Adjustable speed control
Step by step mode (1 component at a time)
Empty pocket check (optional)
Barcode reader input
Serial connection for label printer or PC
Selection of the operator (10 operators can be memorized with 8 alphanumerical chars everyone)
Internal clock (1 week backup)
Memory that stores the last 500 counting data
Memory storage for subtotals
2 side handles for easy transport.


8301.131  County-S EVO - 230V/50-60 Hz
8301.133  County-S EVO - 230V/50-60 Hz - with Empty Pocket Check

8301.141  County-S EVO - 115V/50-60 Hz
8301.143  County-S EVO - 115V/50-60 Hz - with Empty Pocket Check

8301.350  ISO9000 Traceable™ Certificate




8301.150
Support for reel larger than 400mm (15.74")

8301.021
Aluminum Empty reel
- Inner 150 / outer 360mm diameter.
Tape height from 8 to 56mm


Software "EVO Manager"



Software "EVO Manager" to connect the County-S EVO to a PC
With this free software it's possible to work in 3 modes:
- Custom Printer Label to print the label on a printer connected to the PC
- Sendkeys to send input to a target program (ie Microsoft Excel). The target program will receive inputs as from a keyboard.
- Datalogger to import on a table all the records of the last 500 works performed. This table can be exported in a common spreadsheet (ie Microsoft Excel).

License:
Freeware
S.O.: Windows XP/7/8/10
File size: 604 Kb

EvoManager1.3 The program was tested for many printers.
Test it now, even without the counter, for compatibility.

                                                                                                                                                                                                                                                       top



COUNTY-S EVO with EPC (Empty Pocket Check)

SMD reels sometimes have missing components that most counters can't detect.

The County-S EVO equipped with EPC (model 8301.133 and 8301.143) not only counts the sprocket holes but also checks each pocket to verify that the component is really inside.
In case of missing parts the machine can stop immediately after a desired consecutive missing component number (Stop Number is selectable from 0 to 9)
When the count ends the display shows both the number of detected components and the number of missing components.
As an additional benefit, the EPC option stops at the last components of the reel (SMD reels have about 400mm of tape leader without components). This make it easy to rewind.



NOTE:
EPC option works only on black plastic tapes from 8 to 54mm of height.

County S Specs PDF
